Level indicators are indispensable components for level control in containers and process plants. They ensure process reliability, prevent overfilling and enable precise monitoring – whether in chemical, energy, food or water technology. Our selection includes bypass level indicators, sight glass indicators and glass tube indicators in various designs for standard and high-pressure applications.
| Feature | BNA | LGG | Type 120 | Type 121 | Type 126 | Type 128 |
| Nominal pressure | up to 400 bar | up to 250 bar | PN 25 | PN 25 | PN 10 | PN 25 |
| Nominal size | DN 15 – DN 100 | DN 15 – DN 50 | DN 15 – DN 20 | DN 15 – DN 25 | DN 15 | DN 15 – DN 25 |
| Temperature | -196 °C to +450 °C | -196 °C to +374 °C | -10 °C to +200 °C | -10 °C to +200 °C | -10 °C to +100 °C | -10 °C to +200 °C |
| Material | Stainless steel, PP, PVDF | Steel, CrNi steel | Brass, stainless steel 1.4571 | Stainless steel 1.4571 | Brass | Stainless steel 1.4571 |
| Gasket | PTFE, special option | Graphite, mica | Flat gasket | Flat gasket | Flat gasket | Flat gasket |
| Special feature | Level indicator without power, magnetic display | Direct display with reflective/ transparent glass | Compact glass tube display for tank construction | Intermediate holder for glass tube indicator | Valve fluid level indicator, light | Valve fluid level indicator with flange |
For standard, high-pressure and special applications
Mechanical display without auxiliary power
Stainless steel, special materials for aggressive media
Special connections, heating jacket, ATEX-compliant versions
CE, ATEX, IECEx, PED-compliant
Level indicators are indispensable components in tank construction and process technology, as they enable continuous and reliable level control. They are used in storage tanks, pressure vessels, reactors and mixing vessels and ensure process safety by preventing overfilling or dry running.
Thanks to their robust design and the possibility of customization – for example with special connections, heating jackets or ATEX-compliant versions – our level indicators can be perfectly integrated into your system. They are suitable for aggressive media, high temperatures and pressures and can also be used in hygienic applications such as the food and pharmaceutical industries.
We not only offer standard solutions, but also customized versions that are precisely tailored to your requirements. This gives you a product that combines functionality, safety and durability – ideal for use in chemical, energy, water and food technology.
Bypass, sight glasses and glass tube indicators for different applications.
Yes, BNA up to 400 bar and LGG up to 250 bar.
No, all displays function mechanically without auxiliary power.
Yes, variants are available for potentially explosive atmospheres.
Yes, special materials, connections and heating jackets are possible.
