Our globe valves offer maximum safety and reliability for demanding applications in chemical, energy and process plants. Whether bellows valves for emission-free sealing, robust stuffing box valves, compact needle valves for high pressure or soft-sealing valves for water technology – you will find the right solution here. We also offer automation solutions and heating jacket options for individual requirements.
Bellows sealed valves are the first choice for applications where emission-free sealing is required. They are suitable for aggressive media, high temperatures and pressures. Ideal for chemical, energy and power plant applications.
| Property | Fig 114 | Fig 231 | BOA-H | NORI 40 ZXLBV / ZXSBV |
| Material | Cast steel | Stainless steel | Cast iron/cast steel | Cast steel |
| Nominal pressure | PN 40 | PN 16 | PN 16 / PN 40 | PN 25 / PN 40 |
| Nominal size | DN 15 to DN 200 | DN 65 to DN 200 | DN 15 to DN 350 | DN 10 to DN 200 |
| Temperature | -10 to +400 °C | -60 to +300 °C | -10 to +450 °C | -10 to +450 °C |
| Special feature | TA-Luft & ATEX | Double-walled bellows | Suitable for thermal oil | Two-part stem |
Stuffing box valves are robust and proven for standard applications with high pressures and temperatures. They offer reliable sealing and are easy to maintain.
| Property | Fig 101 | Fig 231 | NORI 40 ZXL / ZXS | NORI 40 ZXLF / ZXSF |
| material | Cast iron | Cast steel | Cast steel | Cast steel |
| Nominal pressure | PN 16 | PN 40 | PN 25 / PN 40 | PN 25 / PN 40 |
| Nominal size | DN 15 to DN 250 | DN 15 to DN 250 | DN 10 to DN 400 | DN 10 to DN 200 |
| Temperature | -10 to +300 °C | -10 to +400 °C | -10 to +450 °C | -10 to +450 °C |
| Special feature | Cost-effective for standard | High pressure resistance | Large nominal sizes up to DN400 | Non-rotating stem |
Soft-seated valves are ideal for water and HVAC applications. They provide a reliable seal at low temperatures and pressures.
| Feature | BOA-Compact | |||
| material | Cast iron | |||
| Nominal pressure | PN 10 / PN 16 | |||
| Nominal size | DN 15 to DN 200 | |||
| Temperature | -10 to +80 °C | |||
| Special feature | Compact design for HVAC |
Needle valves are designed for precise control and shut-off in high-pressure systems. They are compact and ideal for test benches and special applications.
| Eigenschaft | Fig 110 | Fig 108 |
| material | Steel / stainless steel / brass | Steel / stainless steel |
| Nominal pressure | PN 400 | PN 160 to PN 640 |
| Connection | G1/8-G1 / flange / butt weld ends | G¼-G1½ |
| Temperature | -20 to +350 °C | -10 to +400 °C |
| Special feature | Compact design | Optional non-return function |
for all pressure and temperature ranges
and long service life
Together with our strong partners, we develop customized automation solutions for globe valves. Whether pneumatic or electric actuators, positioners, limit switches or solenoid valves – we offer complete systems from a single source.
Our globe valves can be individually equipped with high-quality stainless steel heating and leakage jackets. These enable the safe heating, temperature control and leakage monitoring of viscous, temperature-dependent or safety-critical media.
Thanks to our customized design, we adapt each jacket precisely to the respective valve – including production, welding, connection assembly and leak testing. We can provide suitable valves directly on request. Ideal for the process industry, chemicals, energy, food technology and wherever process reliability and constant media conditions are crucial.
In addition to our wide range of globe valves, we offer customized solutions for your processes in cooperation with Industriefabrik Schneider GmbH:
Your advantages: Shorter installation times, greater operational reliability, individual adaptation to your requirements
DIN EN 1092, DIN EN 558, DIN EN 12266, optional TA-Luft and ISO 15848.
Yes, for zone 1+21 and zone 2+22.
Yes, depending on the manufacturer. We offer complete solutions with actuators and controls.
Individual designs made of stainless steel, tested for leaks.
Depending on type up to +450 °C.
